Weight

4.2KG

4.7KG

5.1KG

4KG

Dimension

Φ280X160mm

Φ488X350mm

Φ488X350mm

Φ280X160mm

Wattage

150-250W

150-250W

150-250W

150-250W

LED Chip

5050

5050

5050

5050

LED Voltage

30-48V

30-48V

30-48V

30-48V

Power Brand

Inventronics,Sosen, Maso(Isolated intelligent dimming power supply)

Input Voltage

AC85-265V 、 AC36V ADC36V AC24V DC24V

Heat Sink

Cold forging process of aviation aluminum,

Height≥50mm,Length≥5-10, Thickness≥12mm; Quantity≥ 35 pieces

Material

6063-T3 Aluminum for aviation

IP Rating

IP67

anti-corrosion

WF2

Power Factor

>0.95

CRI

Ra>80

CCT

2700-6500K

Luminous Efficiency

≥130Lm/W

Emergency Time

120 Minutes

Cable

G3/4” or Φ 8-12mm

Beam Angle

30°60°110°

Mounting

Ceiling mounted, suspended, wall mounted, U-bracket mounted, floodlight mounted, high pole mounted

Lifespan

>100,000 Hours

Warranty

7 Years
