Wattage(W)

400-500

500-600

1000-1200

1500-1600

Size(mm)

  356*398*434

 423*490*509

 520*592*649

570*724*772

Weight(KG)

11

16

22

38

LED Chip

5050/3737

3030/5050/3737

3030/5050/3737

3030/5050/3737

Power Supply

Inventronics, Sosen...(Isolation type with intelligent dimming power supply)

Input Voltage

AC85-265V 、 AC36V ADC36V AC24V DC24V

Beam Angle

15°/30°/45°/60°; (15°WITH LED 3737;  30°/45°/60°WITH LED 3030 OR5050)

IP Rating

IP66

IK Rating

IK09

Surge Protection

10kV( Standard); 20kV (Optional)

Power Factor

>0.95

CRI

Ra70/ Ra80/Ra90 (Optional)

CCT

2700-6500K

Working Temperature

-40°C to 50°C (-40°F to 122°F)

Luminous Efficiency

≥140Lm/W

Mounting

U-bracket,Ceiling Mount,Arm Mount (with safety rope)

Lifespan

>100,000 Hours

Warranty

7 years
