Product Specifications
Parameter | Specification |
Power | 50W / 145W / 150W / 280W / 300W / 400W / 500W |
Luminous Efficiency | 140–160 lm/W |
Input Voltage | AC100–277V / 277-480V |
Power Factor | ≥0.95 |
Beam Angles | 60° |
CCT | 3000K / 4000K / 5000K / 5700K/ 6500K |
CRI | Ra ≥ 80＋ |
IP Rating | IP66 |
IK Rating | IK10 |
Housing Material | Die-cast Aluminum + Tempered Glass |
Operating Temp | -30°C ~ +50°C |
Control Options | DALI / DMX512 / 0–10V Dimming |
Surge Protection | 10KV / 20KV |
Certifications | CE / RoHS / ENEC / ETL / DLC |
Warranty | 5 Years |
Lifespan | 50,000 Hours |
Protection & Reliability
| Description | |
🌧️ | IP66 Waterproof | Perfect for outdoor environments exposed to rain and dust. |
⚡ | 10KV/20KV Surge Protection | Ensures electrical safety and system stability. |
💥 | IK10 Impact Resistant | Resists mechanical shock and sports ball impacts. |
🌡️ | Thermal Control System | Prevents overheating and maintains LED efficiency. |
🔋 | 50,000H Lifespan | Long-term durability for sports venues and arenas. |
Application Scenarios
🏟️ Football / Soccer Stadiums
🏀 Basketball & Tennis Courts
🏁 Race Tracks & Outdoor Arenas
🏐 Multi-purpose Sports Fields
⛳ Golf Driving Ranges
🚧 High Mast Floodlighting Projects
⚓ Ports & Outdoor Industrial Yards
Shenzhen Oudi Optoelectronic Technology Co., Ltd, located in Shenzhen China, has focused on LED lighting for 20 years, and has ranked among the top 25 of LED industrial lighting companies in Shenzhen. We are a high-tech enterprise with R&D,production,sales and technical support.
